Comparing Lerna-Storybook Architectures

Published: 2019-01-24

⚔ Conflicting Philosophies

When creating a Lerna project with React and Storybook, there are two places in which Storybook can live:

  • As a package managed by Lerna
  • As a sibling to Lerna in the project root

There seems to be conflicting philosophies within the community when it comes to these two approaches:

While I am only including 2 of each, including Storybook in the project root is way more popular.

I created storybook-architecture-demo which contains both architectures, so they can be compared side by side:

🤓 My Take

While the method shown in storybook-in-root is more popular, I cannot figure out why. I see no benefit of architecting in with Storybook living in the project root.

Conversely, the storybook-as-package strategy has many advantages over storybook-in-root

💅 Less Clutter in Root

The root folder of storybook-as-package has one concern (Lerna), while storybook-in-root. This difference makes the storybook-in-root file structure more disjointed:

$ ls -la storybook-as-package
total 1448
drwxr-xr-x     8 rsoni  domain users     272 Jan 24 19:54 .
drwxr-xr-x     7 rsoni  domain users     238 Jan 24 19:53 ..
-rw-r--r--     1 rsoni  domain users     111 Jan 24 18:07 lerna.json
drwxr-xr-x  1485 rsoni  domain users   50490 Jan 24 19:10 node_modules
-rw-r--r--     1 rsoni  domain users     296 Jan 24 19:06 package.json
drwxr-xr-x     5 rsoni  domain users     170 Jan 24 18:34 packages
-rw-r--r--     1 rsoni  domain users     366 Jan 24 19:54 readme.md
-rw-r--r--     1 rsoni  domain users  727596 Jan 24 19:07 yarn.lock

$ ls -la storybook-in-root
total 1448
drwxr-xr-x    10 rsoni  domain users     340 Jan 24 19:55 .
drwxr-xr-x     7 rsoni  domain users     238 Jan 24 19:53 ..
drwxr-xr-x     4 rsoni  domain users     136 Jan 24 19:32 .storybook
-rw-r--r--     1 rsoni  domain users     111 Jan 24 19:21 lerna.json
drwxr-xr-x  1485 rsoni  domain users   50490 Jan 24 19:32 node_modules
-rw-r--r--     1 rsoni  domain users     618 Jan 24 19:32 package.json
drwxr-xr-x     4 rsoni  domain users     136 Jan 24 19:21 packages
-rw-r--r--     1 rsoni  domain users     373 Jan 24 19:55 readme.md
drwxr-xr-x     3 rsoni  domain users     102 Jan 24 19:32 src
-rw-r--r--     1 rsoni  domain users  727596 Jan 24 19:32 yarn.lock

In the storybook-as-package example the storybook setup script functions better:

This pollution also extends to the package.json:

$ cat storybook-as-package/package.json
{
  "name": "root",
  "private": true,
  "scripts": {
    "build:all": "lerna run build --parallel",
    "install:all": "lerna bootstrap && lerna link",
    "start:all": "lerna run start --parallel"
  },
  "devDependencies": {
    "lerna": "^3.10.5"
  },
  "workspaces": [
    "packages/*"
  ]
}

$ cat storybook-in-root/package.json
{
  "name": "root",
  "private": true,
  "scripts": {
    "build:all": "lerna run build --parallel",
    "install:all": "lerna bootstrap && lerna link",
    "start:all": "lerna run start --parallel",
    "storybook": "start-storybook -p 9009",
    "build-storybook": "build-storybook"
  },
  "devDependencies": {
    "lerna": "^3.10.5",
    "@storybook/react": "^4.1.11",
    "@storybook/addon-actions": "^4.1.11",
    "@storybook/addon-links": "^4.1.11",
    "@storybook/addons": "^4.1.11",
    "@babel/core": "^7.2.2",
    "babel-loader": "^8.0.5"
  },
  "workspaces": [
    "packages/*"
  ],
  "dependencies": {}
}

For onboarding new developers to the project, keeping things simple is a huge advantage. The less complexity the better.

📡 Dependency Management

Since Storybook is managed by the root package.json in storybook-in-root, commands like lerna bootstrap and lerna link do not work.

When Storybook is managed by Lerna, peerDepenencies (React, Flow, Typescript), can be properly resolved.

Additionally, storybook-as-package mimicks real work imports better thank storybook-in-root:

$ cat storybook-in-root/src/stories/index.js | grep ExternalComponent
import ExternalComponent from "../../packages/external-component/dist/index.es";

$ cat storybook-as-package/packages/storybook/src/stories/index.js | grep ExternalComponent
import ExternalComponent from "@lerna-storybook-demo/external-component";

🏠 Local Development

With the storybook-as-package architecture, Lerna can serve Storybook, a React server, and build an External Library all in one start command: "start:all": "lerna run start --parallel".

With storybook-in-root, a separate yarn storybook server is required.

✌️Conclusion

I see no reason to go with storybook-in-root. There are no apparent advantages it has over storybook-as-package. While storybook-as-package has many over storybook-in-root.
